28th March 2025

Health and Safety Award

AMS No-Dig Ltd Honoured with Certificate of Commendation for Outstanding Achievement in Health and Safety

North Lincolnshire, March 2025 – AMS No-Dig Ltd has been recognised for its unwavering commitment to health and safety with the prestigious Certificate of Commendation for Outstanding Achievement in Health and Safety, awarded by the North Lincolnshire Health and Safety Group. The accolade highlights the company’s consistent efforts to prioritise the wellbeing of its employees and ensure that safety remains at the forefront of its operations.

The recognition underscores AMS No-Dig Ltd’s proactive approach to creating a safe and secure working environment, particularly in the complex and often hazardous industry of trenchless technology and underground construction. The company’s comprehensive safety protocols, training programs, and diligent adherence to industry regulations have set a high standard for best practices in health and safety within the sector.

A Commitment to Safety Excellence

AMS No-Dig Ltd’s focus on health and safety is embedded in its corporate culture, with the company continually seeking to improve safety measures through ongoing employee training, regular safety audits, and the adoption of cutting-edge technology. The recognition from the North Lincolnshire Health and Safety Group highlights the company’s consistent track record in reducing workplace incidents and fostering a culture where safety is everyone’s responsibility.

As a specialist in non-invasive trenchless technologies, AMS No-Dig Ltd operates in environments that pose potential risks, from confined spaces to heavy machinery operations. The company’s ability to mitigate these risks through careful planning, innovative safety solutions, and the commitment of its staff has been a key factor in its success.

21st December 2024

D100x140 More about our new Vermeer drilling rigs

admin Uncategorised

With a maximum rotary torque output of 14,000 ft-lb (18,981.5 Nm) and rotational speeds up to 203 rpm, the D100x140 horizontal directional drill offers an exceptional punch in response to the most challenging projects. The rig can use 15-ft or 20-ft (4.6-m or 6.1-m) lengths of 3.5-in (8.9-cm) Firestick drill rod.

D100x140 More about our new Vermeer drilling rigs

OPEN-TOP VICE

An angled, open-top vice allows for the passage of larger tooling. Because of the large opening, operators can also use it to break out tooling.

STACKABLE ROD BOXES

Stackable rod boxes are easy to use with a single pin and patent-pending auto lock

DRILL EFFICIENTLY

The D100x140 S3 features the DigiTrak Aurora full-colour touchscreen display, delivering an engaging experience, which helps make a driller’s day more productive.

OPTIONAL ONBOARD CRANE

With the option of an onboard knuckleboom style crane to reduce the amount of support equipment needed on site

INCREASE YOUR RANGE

Unique four-bar linkage rack and additional pads allow operators to set up entry angles of 11-24 degrees – increasing the range attainable with tracks fully on the ground.

FIRESTICK DRILL ROD

Experience the difference that has made one-piece forged Firestick drill rod the industry benchmark.

D100x140 S3 NAVIGATOR®HORIZONTAL DIRECTIONAL DRILL Specifications

GENERAL WEIGHTS AND DIMENSIONS
Min transport length (15 ft [4.6 m] rod option): 31.4 ft (9.5 m)
Min transport length (20 ft [6.1 m] rod option): 36.4 ft (11.1 m)
Min transport width: 102 in (254 cm)
Min transport height: 11.5 ft (3.4 m)
Min weight (15 ft [4.6 m] rod option): 50,300 lb (22,815.7 kg)
Min weight (20 ft [6.1 m] rod option): 52,500 lb (23,813.6 kg)

ENGINE
Make/Model: Caterpillar
Fuel type: Ultra-low sulfur diesel
Max engine rpm: 2200 rpm
Gross horsepower: 275 hp (205 kW)
Cooling method: Liquid
Aspiration: Turbocharged
Emissions rating: Tier 4 Final (EU Stage V)

OPERATIONAL
Thrust/Pullback: 100,000 lb (444.8 kN)
Max carriage speed: 205 fpm (62.5 m/min)
Max spindle torque (low at max engine rpm): 14,000 ft-lb
(18,981.5 Nm)
Max spindle speed: 230 rpm
Max ground drive speed: 1.7 mph (2.7 km/h)
Noise level at operator’s ear: 82 dB(A)

FLUID CAPACITIES
Fuel tank: 115 gal (435 L)
Hydraulic tank: 80 gal (302.8 L)

DRILLING FLUID OPTION ONE (APLEX)
Max flow: 200 gpm (757 L/min)
Max pressure: 1,000 psi (6.9 MPa)

DRILLING FLUID OPTION TWO (KERR)
Max flow: 230 gpm (870.6 L/min)
Max pressure: 1,100 psi (7.6 MPa

OPTIONAL CRANE
Weight: 2,600 lb (1,179.3 kg)
Max lifting capacity at 13 ft (3.95 m): 5,070 lb (2,300 kg)
Max lifting capacity at 19.5 ft (5.95 m): 3,970 lb (1,800 kg)
Rotation: 360°
Max reach: 19.5 ft (5.95 m)

FEATURES
Drilling lights: Standard
Stakedown system: Optional
Remote ground drive control: Standard
Strike alert: Standard
Remote lockout: Standard

DRILL PIPE OPTION ONE
Type: Firestick drill rod
Length: 15 ft (4.6 m)
Joint diameter: 4.375 in (11.1 cm)
Pipe diameter: 3.5 in (8.9 cm)
Weight: 261 lb (118.4 kg)
Min bend radius: 197 ft (60 m)
Rod carrying capacity: 135 ft (41.1 m) with permanent rod box,
270 ft (82.3 m) with stacked box

DRILL PIPE OPTION TWO
Type: Firestick drill rod
Length: 20 ft (6.1 m)
Joint diameter: 4.375 in (11.2 cm)
Pipe diameter: 3.5 in (8.9 cm)
Weight: 374 lb (169.6 kg)
Min bend radius: 197 ft (60 m)
Rod carrying capacity: 180 ft (54.9 m) with permanent rod box,
360 ft (109.7 m) with stacked box

OPTIONAL STAKE DOWN
Spade Stakedown
Aggressive Rotary Stakedown
Weight: 1,000 lb (454 kg)

20th December 2024

D60x90 – More about our new Vermeer drilling rigs

admin Uncategorised

The D60x90 S3 Navigator® horizontal directional drill is significantly more powerful and quieter than its predecessor — with the interactive Aurora® digital display to help get the job done faster and more efficiently.

This machine packs all these valuable benefits into a modest footprint.

With up to 60,000 lb (266.9 kN) of thrust and pullback — an impressive 17 hp (13 kW) increase over its previous model (D60x90 Navigator® horizontal directional drill) — the D60x90 S3 is the drill that will take productivity to a whole new level.

D60x90 – More about our new Vermeer drilling rigs

IMPRESSIVE SIZE-TO-POWER RATIO.
The D60x90 S3 boasts up to 60,000 lb (267 kN) thrust/pullback and 9,000 ft-lb (12,202.4 Nm) of rotational torque at just 100″ (254 cm) wide and 26′ long (7.9 m), so it’s qualified for a range of installation specifications even in congested urban sites.

INCREASED POWER. The D60x90 S3 boasts a sizeable 17 hp (12.7 kW) increase over its predecessor, the D60x90, giving operators more power for drilling in difficult ground conditions.

SIGNIFICANTLY QUIETER. The D60x90 S3 has a guaranteed sound power rating of just 107 dBA – 12 dBA lower than its predecessor the D60x90 – resulting in reduced noise at operator’s ear [83 dBA], increased operator comfort and less noise disturbance in residential or urban areas.

LARGE OPEN-TOP VISE DESIGN. The D60x90 S3 features a large open-top vise design for the purpose of removing and adding tooling.

CONVENIENT ROD LOADING. Easy-to-operate and reliable rod loader is inspired by the popular and proven D24x40 Series II design.

AURORA™ TOUCHSCREEN DISPLAY.
Interactive, full-color display provides real-time location information plus tools to complete drilling activities more efficiently, and can replace the need for hard copy bore plans.

D60x90 S3 NAVIGATOR HORIZONTAL DIRECTIONAL DRILL Specifications

GENERAL WEIGHTS AND DIMENSIONS
Min transport length: 29.5′ (9 m)
Min transport width: 100″ (254 cm)
Min transport height: 104″ (264.2 cm)
Weight: 39,000 lb (17,690.1 kg)

ENGINE
Make/Model: CAT 7.1
Fuel type: Ultra low sulfur diesel
Max engine rpm: 2200 rpm
Gross horsepower: 202 hp (151 kW)
Max torque: 642 lb-ft (870 Nm)
Displacement: 433.3 cu-in (7.1 L)
Cooling method: Liquid
Aspiration: Turbo Charged
Emissions rating: Tier 4 Final (EU Stage IV)

OPERATIONAL
Thrust/Pullback: 60,000 lb (266.9 kN)
Max carriage speed at max engine rpm: 175 fpm (53.34 m/min)
Max spindle torque (low at max engine rpm): 9000 ft-lb (12,204 Nm)
Max spindle speed at max engine rpm: 200 rpm
Min bore diameter: 6″ (15 cm)
Max ground drive speed at max engine rpm (fwd): 3.7 mph (6 km/h)
Noise level at operator’s ear: 83 dBA
Drill rack angle: 12°-15° (21.3%-26.8%

DRILLING FLUID SYSTEM
Max flow: 150 gpm (567 L/min)
Max pressure: 900 psi (6.2 MPa)

FEATURES
Breakout system: Standard top load hydraulic vise
Drilling lights: Standard
Flow indicator: Standard
Stakedown system: Optional
Strike alert: Standard
Remote lockout: Standard

DRILL PIPE OPTION ONE
Type: Firestick® drill rod
Length: 15′ (4.6 m)
Rod diameter: 2.875″ (7.3 cm)
Weight: 180 lb (81.7 kg)
Bend radius: 168.7′ (51 m)
Onboard capacity: 600′ (182.9 m)

DRILL PIPE OPTION TWO
Type: Firestick drill rod
Length: 15′ (4.6 m)
Rod diameter: 3.5″ (8.9 cm)
Weight: 250 lb (113.5 kg)
Bend radius: 197.7′ (60 m)
Onboard capacity: 360′ (109.7 m)

20th December 2024

New Vermeer Directional Drilling Rigs

admin Uncategorised

Due to an expanding forward order book AMS Trenchless have invested in expansion of our fleet of drilling rigs.

Earlier in the year, we took delivery of two brand new Vermeer Directional Drilling rigs to complement our existing fleet of Vermeer and Prime Drilling directional drilling rigs with up to 250-ton pull-back capacity.

The pictures show the Vermeer D100x140 arriving at our base in Scunthorpe and being accepted by Managing Director George Aitkenhead.

We also took delivery of a brand new D60x90 directly to site and it was put to work on a major project near Norwich in Norfolk immediately.

29th November 2024

AMS Trenchless win Murphy Energy supply chain partner of the year!

admin Uncategorised

AMS Trenchless have won Murphy’s Energy Supply Chain partner of the year at an awards ceremony held last week.

Our Managing Director, George Aitkenhead, attended Murphy’s Annual Supplier awards – an event celebrating the valued impact of Murphy’s supply chain partners.

The night was Murphy’s largest awards event yet, bringing together over 300 members of their supply chain who support their project teams to successfully deliver world-class infrastructure.

There were ten award categories – covering all elements of their business and core operating goals and values – winners were selected for their proactive, collaborative efforts to support colleagues’ safety, ensure sustainability and foster long-term innovation.

Speaking after the event, Ian Holcroft, Murphy Procurement Director said: “This year’s awards were another fantastic evening celebrating the success of our supply chain partners who are very much part of the Murphy family and our One Team approach. Congratulations to all our winners, we look forward to continuing working with you and all our trusted partners in the year ahead.”

Full details and list of winners are available on Murphy’s website: https://www.murphygroup.com/murphy-celebrate-their-supply-chain-at-annual-awards/

AMS Trenchless win Murphy Energy supply chain partner of the year!

6th January 2020

iPads donated to a local school by AMS Trenchless Specialists

admin Uncategorised

AMS Trenchless were pleased to present 3 iPads to pupils from Ysgol Penllwyn, a local school in the Cwm Rheidol area, Aberystwyth, Wales following our work in the area. Operations Director Peter Guilliatt presented the iPads to the pupils before Christmas.

1st October 2019

New DX40-55 Vermeer Directional Drilling rig for AMS Trenchless

admin Uncategorised

AMS Trenchless Specialists have recently taken delivery of a brand new Vermeer D40x55 to add to our fleet of mid sized Vermeer directional drilling rigs.

To complement the new rig, we also have a newly converted lorry and trailer, complete with on board mud mixing system to form a complete package with the new drilling rig.

The new lorry and rig can be seen heading straight out to work in the pictures below.

New DX40-55 Vermeer Directional Drilling rig for AMS Trenchless

1st September 2019

AMS No-Dig Ltd will now trade as AMS Trenchless Specialists

admin Uncategorised

AMS No-Dig Ltd have recently carried a full re-branding excercise in association with a local Lincoln based design agency.

The re-brand involved the development of a new logo and colour scheme, a new range of ‘AMS’ fonts and most importantly a new trading name. AMS No-Dig Ltd will now be trading as AMS Trenchless Specialists, and our website and domain name have been updated to match – www.amstrenchless.com

We now have a range of logo styles for the different activities carried out by the company, and these will be used on all documentation from now on.

12th April 2019

New Horizontal Directional Drilling contract with Orsted on world’s biggest offshore wind farm

admin Uncategorised

AMS Trenchless have recently signed a second contract with Orsted to carry out Horizontal Directional Drilling for the landfall cables for the world’s largest offshore windfarm – Orsted’s Hornsea 2, which will power over 1.3 million homes.

AMS will undertake Horizontal Directional Drilling (HDD), a method of installing ducting and cables beneath existing infrastructure without disruption, at the landfall site in Horseshoe Point where the offshore cables meet the onshore cables.

This contract builds on the existing relationship between the East-coast firm and Ørsted, the world’s largest offshore wind developer, following previous works for Hornsea Two’s sister project, Hornsea One.

Hornsea Two is in the early stages of construction, and when complete in 2022 it will be able to power well over 1.3 million homes, overtaking Hornsea One, due for completion next year, as the world’s biggest offshore wind farm.

Duncan Clark, project director for both Hornsea One and Two, said: “We’re delighted to welcome another UK firm to join us in building the UK’s largest renewable energy project currently under construction. Lancashire-based VolkerInfra are installing the onshore cable, the onshore substation is being built by Balfour Beatty, and the fact that AMS Trenchless Specialists, who are based literally up the road from our onshore site, will be working with us again is a testament to their previous work on Hornsea One.”

Using Horizontal Directional Drilling means that the cable can be buried underground without using trenches or disrupting the existing sea defences in the intertidal area, that links the offshore infrastructure with the onshore infrastructure.

George Aitkenhead, Managing Director, AMS Trenchless Specialists said: “We feel proud to again have the opportunity to work on a project that will make a significant difference to the UK’s clean electricity system. HDD is a fast, efficient and environmentally friendly way to install this much needed infrastructure, whilst minimising disruption. It’s great to see global firms, such as Ørsted, recognise our wealth of experience and continue place such big contracts with local firms like ours. For us, the offshore wind industry provides big opportunities in a market that is only going to keep growing.”

This contract will be carried out by our new Prime Drilling PD250 RP/C

To read the full Orsted press release, click here: https://orsted.co.uk/en/Media/Newsroom/News/2019/04/Scunthorpes-AMS-Trenchless-Specialists-wins-big-on-worlds-biggest-offshore-wind-farm-Hornsea-Two

1st February 2019

New fleet of vans added by AMS Trenchless

admin Uncategorised

AMS Trenchless Specialists have taken delivery of a fleet of new vans, these are mainly Ford Transit Custom with some smaller VW Caddy vans included too.

The vans are vinyl wrapped using our new logo, colour scheme and branding, and all include a photographic image of our equipment in action on their rear doors.

New fleet of vans added by AMS Trenchless
